Gyroscope Apparatus
Technical Description:
The moments generated by the gyroscopic effect can be investigated using this unit. The basic component is a flywheel driven about its own axis. This is mounted together with its drive motor as a yoke and forms the gyroscope. This arrangement is placed in rotation about a vertical axis with the aid of a second motor. The rotational speeds of both motors are electronically regulated and displayed digitally. The gyroscopic moment is preselected by simply positioning a counterweight at different radii. A transparent cover provides protection against touching the rotating parts. The gyroscope is a portable table unit. All that is required for operation is a mains supply.
Specification:
1. Demonstration and student experiments on the moments generated on a gyroscope 2. Adjustable gyroscope speed 3. Adjustable gyroscope frame speed 4. Mass of the gyroscope body: 65g 5. Two independently controllable electric motors 6. Transparent protective cover made of plastic 7. lxwxh 420x400x310mmTechnical Data:
- Gyroscope rotational speed: 1000...6000rpm - Gyroscope frame rotational speed: 5...63rpm - Gyroscope weight: 65g - Radius range of the weight: 0...95mm
