Pivot Friction Apparatus
Pivot Friction Apparatus: demonstrates the relationship between friction torque and axial thrust; determines the influence of bearing cone angle.
- Price
- On request, by quantity and destination
- Tender documents
- Specification sheet and quotation on request
Product details
Pivot Friction Apparatus
Specification:- Demonstrates the relationship between friction torque and axial thrust; determines the influence of bearing cone angle.
- The wall mounted apparatus consists of a rotating circular table on a vertical shaft, with a variety of interchangeable end pivots and seatings.
- End pivots in brass and steel seatings have inclusive core angles of 60, 90, 120 and 180 (flat) degrees; additionally a ball thrust bearing may be installed.
- Thrust loads applied directly onto the rotating table.
- Pure torque applied by loading cords and weight hangers acting over pulleys onto the rotating table.
- Pivots brass, and the seating mild steel.
- An Instruction manual for student and lecturer supplied.
- Set of weights
